| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | OLKOPTO |
| Certification: | RoHS FCC CE GS UL FDA etc |
| Model Number: | OLSP311XL-CD40 |
| Minimum Order Quantity: | 1pc |
| Packaging Details: | Individual package Or 10pcs/pallet Or 20pcs/pallet |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T or Net 30 days |
| Supply Ability: | 80-120k per month |
| Data Rate: | 11.3Gb/s Bit Rates | Compatibility: | Brocade 10G-SFPP-ER40 |
|---|---|---|---|
| Form Factor: | SFP+ | Wavelength: | 1310nm |
| Distance: | 40km | Connector: | LC Duplex |
| DDM/DOM: | Supported | Optical Components: | DFB 1310nm |
| Fiber Type: | SMF | Temperature: | 0~70 °C |
10G-ER SFP+ 1310nm 40km LC SMF SFP Transceiver Module Compatible Brocade 10G-SFPP-ER40
Optical Characteristics (TOP(C) = 0 to 70 ℃, TOP(I) =-40 to 85 ℃,VCC = 3.13 to 3.47 V)
| Parameter | Symbol | Min. | Typ | Max. | Unit | Note |
| Transmitter | ||||||
| Operating Wavelength | λ | 1530 | 1570 | nm | ||
| Ave. output power (Enabled) | PAVE | -2 | 4 | dBm | 1 | |
| Side-Mode Suppression Ratio | SMSR | 30 | dB | |||
| Extinction Ratio | ER | 4 | dB | |||
| RMS spectral width | Δλ | 1 | nm | |||
| Dispersion penalty | TDP | 4 | dB | |||
| Relative Intensity Noise | RIN | -128 | dB/Hz | |||
| Output Optical Eye | Compliant with IEEE 0802.3ae | |||||
| Receiver | ||||||
| Operating Wavelength | 1260 | 1600 | nm | |||
| Receiver Sensitivity @10.3G | -16 | dBm | 2 | |||
| Path Penalty | PP | 2 | dB | |||
| Overload | PAVE | +0.5 | dBm | |||
| LOS Assert | Pa | -30 | dBm | |||
| LOS De-assert | Pd | -18 | dBm | |||
| LOS Hysteresis | Pd-Pa | 0.5 | dB | |||
Notes:
1. Measured with worst ER=5dB
2. PRBS 231 – 1 and BER<10-12.
General Operating Characteristics
| Parameter | Symbol | Min. | Typ | Max. | Unit | Note |
| Data Rate | DR | 9.953 | 10.3125 | 11.3 | Gb/s | |
| Supply Voltage | Vcc | 3.13 | 3.3 | 3.47 | V | |
| Supply Current | Icc5 | 400 | mA | |||
| Operating Case Temp. | Tc | 0 | 70 | °C | ||
| TI | -40 | 85 |
Product Features
• Supports 11.3Gb/s bit rates
• Duplex LC connector
• Hot-pluggable SFP+ footprint
• Uncooled 1310nm DFB transmitter, PIN photo-detector
• Applicable for 40km SMF connection
• Low power consumption, < 1W
• Digital Diagnostic Monitor Interface
• Optical interface compliant to IEEE 802.3ae 10GBASE-LR
• Electrical interface compliant to SFF-8431
• Operating case temperature: Commercial:0 to 70 °C
Applications
• 10GBASE-LR/LW at 10.3125Gbps
• 10G Fiber Channel
• CPRI and OBSAI
• Other optical links
