| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | OLKOPTO |
| Certification: | RoHS FCC CE GS UL FDA etc |
| Model Number: | OLSP8512L-CDS5 |
| Minimum Order Quantity: | 1pc |
| Packaging Details: | Individual package Or 10pcs/pallet Or 20pcs/pallet |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T or Net 30 days |
| Supply Ability: | 80-120k per month |
| Compatibility: | Juniper | Data Rate: | 1.25Gbps/1.0625Gbps |
|---|---|---|---|
| Form Factor: | SFP | Fiber Type: | MMF |
| Wavelength: | 850nm | Distance: | 550m |
| Connector: | LC Duplex | Temperature: | 0~70 °C |
| DDM/DOM: | Supported | Warranty: | 3 Years |
| High Light: | 850nm DOM SFP Optical Transceivers,850nm 550m SFP Optical Transceivers,850nm 550m sfp transceiver |
||
850nm 550m DOM LC MMF SFP Optical Transceivers Module 1000BASE-SX
1000BASE-SX SFP 850nm 550m DOM LC MMF Juniper Compatible Transceiver Module
Product Descriptions
The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 550m transmission distance with MMF. The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
General Operating Characteristics
| Parameter | Symbol | Min. | Typ | Max. | Unit | Note |
| Data Rate | DR | 1.25 | Gb/s | |||
| Supply Voltage | Vcc | 3.13 | 3.3 | 3.47 | V | |
| Supply Current | Icc5 | 220 | mA | |||
| Operating Case Temp. | Tc | 0 | 70 | °C | ||
| TI | -40 | 85 |
Digital Diagnostic Specifications
The OLSP8512L-C(I)DS5 transceivers can be used in host systems that require either internally or externally calibrated digital diagnostics.
| Parameter | Symbol | Units | Min. | Max. | Accuracy | Note |
| Transceiver temperature | DTemp-E | ºC | -45 | +90 | ±5ºC | 1 |
| Transceiver supply voltage | DVoltage | V | 2.8 | 4.0 | ±3% | |
| Transmitter bias current | DBias | mA | 2 | 15 | ±10% | 2 |
| Transmitter output power | DTx-Power | dBm | -11 | 1 | ±3dB | |
| Receiver average input power | DRx-Power | dBm | -21 | 0 | ±3dB |
Notes:
1. When Operating temp.=0~70 ºC,the range will be min=-5,Max=+75
2. The accuracy of the Tx bias current is 10% of the actual current from the laser driver to the laser
3. Internal/ External Calibration compatible.
Features
● Low power consumption, < 0.8W
● Digital Diagnostic Monitor Interface
● Compliant with SFP MSA and SFF-8472
● Very low EMI and excellent ESD protection
● Operating case temperature: Commerical:0 to 70 °C Industrial:-40 to 85 °C
Applications
● Fiber Channel
● Switch to Switch interface
● Switched backplane applications
● Router/Server interface
● Other optical transmission systems
