10gbase Lr XFP Fiber Connector 1310nm 40km Hot Pluggable MikroTik Compatible

Basic Information
Place of Origin: SZ China
Brand Name: OLKOPTO
Certification: ISO9001,ISO14001,OHSAS18001
Model Number: OLXP311XL-CD40
Minimum Order Quantity: 1pcs
Packaging Details: Individual package OR 10 pcs/ pallet OR 20 pcs/ pallet
Delivery Time: 3-5 working days
Payment Terms: TT/Net 30days
Supply Ability: 80-100k per month
Part Number: OLXP311XL-CD40 Data Rate: 10G
Transmission Distance: 40km Low Power Consumption: < 2W
Wavelength: 1310nm Connector Type: LC
High Light:

40km 10G XFP Fiber Connector


40km XFP Fiber Connector


10gbase sr xfp module

10gbase Lr XFP Fiber Connector 1310nm 40km Hot Pluggable MikroTik Compatible


MikroTik Networks 10GBASE-LR XFP 1310nm 40km DOM LC MMF 10G XFP Transceiver Module

Product Features
● Supports 9.95 to 11.3Gb/s bit rates
● Duplex LC connector
● Hot-pluggable XFP footprint
● Cooled 1310nm EML laser ,PIN photo-detector ●Applicable for 40km SMF connection
● Low power consumption, <2W
● Digital Diagnostic Monitor Interface
● No Reference Clock required
● Operating case temperature:
Commerical:0 to 70 °C
Industrial:-40 to 85°C
● 10GBASE-ER/EW 10G Ethernet
● 40km 10G Fibre Channel
● SONET OC-192 IR-2/3,SDH STM S-64.2/3b,ITU-T G.709
● Other optical link
Product Descriptions

Olinkcom’ OLXP311XL-C(I)D40,Small Form Factor 10Gb/s XFP transceivers comply with the current XFP Multi-Source Agreement (MSA) Specification. They also comply with SONET OC-192 IR-2, OC-192 IR-3, SDH STM S-64.2b, STM S-64.3b as well aswith 10-Gigabit Ethernet 10GBASE-ER/EW per IEEE 802.3ae and 40km 10G Fibre Channel applications. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.

Optical Characteristics (TOP(C) = 0 to 70 , TOP(I) =-40 to 85 ,VCC = 3.13 to 3.47 V)

Parameter Symbol Min. Typ Max. Unit Note
Operating Wavelength λ 1290 1310 1330 nm
Ave. output power PAVE 0   6 dBm 1
Optical Modulation Amplitude POMA -2.1     dBm 2
Extinction Ratio ER 4     dB 1
Sidemode Superssion Ratio SMSR 30     dB
SONET Tx Jitter(Peak to Peak) Txj     0.1 UI 3
Tx Jitter(RMS)       0.01 UI 4
Dispersion penalty(@800 ps/nm) TDP     2 dB
Relative Intensity Noise RIN     -130 dB/Hz
Operating Wavelength λ 1260   1620 nm
Receiver Sensitivity@10.3Gbps PSEN1     -16 dBm 5
Receiver Sensitivity@11.3Gbps PSEN2     -15 dBm 5
Overload Pmax -1     dBm
Receiver Reflectance Rrx     -16 dB
Path penalty over 40Km@10.7G         dB 6
LOS Assert Pa -30     dBm
LOS De-assert Pd     -16 dBm
LOS Hysteresis Pd-Pa 0.5     dB

More details of our products:
High Reliable Optical Components and Excellent Design
1. DLB laser and PIN photodiode

2. Thick Gold Finger

3. Plating Hard Gold Shell

Cost-effective and Reliable Transmission


Comprehensive Performance Test with our Advanced Equipment
  • Certified and tested on the automatic quality control system, to ensure the high performance in the actual working environment.Fully Tested for compatibility in our matched switches.

Our Packing & Labeling:

  • Anti-static box
  • Individual package
  • 10pcs/pallet
  • 20pcs/pallet

Our mission is to provide cost effective optical transceiver SFP, SFP+,DAC, QSFP etc with 100% reliable quality, quick lead-time and great after sale service.


Our all modules have 3 years warranty!
